bScope with 5mo CMEX USB 3.0 camera, SAVE with this great Black Friday offer!
Versatile and evolutive!
The well-equipped microscopes of the bScope series are intensively used in universities, small and mid-sized laboratories and for veterinary applications.
The design of the bScope is both ergonomic and evolutive. Height adjustable eyepieces and low stage controls minimize fatigue during long working sessions and therefore providing more comfort for microscopists. The robust and compact size of the bScope with its Cable Storage System allows more working space, safer operation and easy storage
- Versitale and evolutive microscopes
- Robust and attractively priced microscope
- HWF 10x/20 mm eyepieces
- E-plan, E-plan IOS and Plan IOS objectives for bright field and phase contrast
- Rackless integrated X-Y mechanical stage
- 1.5 W LED illumination with rechargeable batteries
- Cable Storage System
- Integrated carrying grip
EYEPIECES: High wide field HWF 10x/20 mm secured eyepieces with 20 mm field of view (Ø 23.2 mm tube)
HEAD: The bScope is equipped with a Siedentopf type head, 360° rotatable, with 30° inclined Ø 23.2 mm tubes. Binocular and trinocular models comes with a diopter ± 5 adjustment on left eyepiece. The interpupillary distance is adjustable between 48 to 76 mm. The models equipped with plan infinity corrected PLi objectives have a unique swiveling system of the eyepiece tubes for ergonomic positioning of the eyepieces in a high and in a low position. The trinocular head comes with a Ø 23.2 mm tube, ensuring maximum flexibility. The prisms inside the heads are designed to minimize the light absorption for perfect digital imaging
NOSEPIECE: Revolving and reversed ball-beared quadruple or quintuple nosepiece
OBJECTIVES: The state-of-the-art production techniques and multi layer coatings used for the manufacturing of the bScope objectives enables the bScope to be used for the most demanding applications. World class spherical aberration correction and modern CNC and assembly technology ensure the perfect centering of the objectives
OBJECTIVE LENSES Quintuple nosepiece E-plan IOS 4/10/S40 S100x
All S40x, S60x and S100x oil immersion objectives are spring loaded. All optics are anti-fungus treated and anti-reflection coated for maximum light throughput
FOCUSING: Double coaxial, low-positioned coarse and fine adjustments with 180 graduations. Precision 1.11 µm, 200 µm per rotation, total travel approximately 19 mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustment is equipped with friction control
STAGE: The bScope is equipped with a scratch resistant 152/197 x 131 mm stage with integrated 75 x 36 mm X-Y rackless mechanical stage, Vernier scale, soft-close removable specimen holder. The rackless stage has no protruding parts, enables more smooth movements and is safer in use. Low-positioned X-Y control knobs prevent fatique during long working sessions. The bScope can be equipped with a heating stage which can be set up to 50° Celsius by a PID temperature controller. Only available with new purchased microscopes
POLARISATION: The bScope has an integrated slot above the nosepiece for an optional polarization filter
ILLUMINATION: The microscopes of the bScope are equipped with a 1.5 W NeoLED adjustable illumination system for increased light output and a 100-240 Vac integrated power supply. On request, rechargeable batteries are also available
KÖHLER ILLUMINATION: A Köhler illumination ensures for all infinity corrected IOS models the highest possible contrast and the maximum achievable resolving power. Generates a uniform illumination of the sample and eliminates all interference from dust on lenses and side glare of the light source. The Köhler illumination is optional for non-IOS models
NEOLED™ ILLUMINATION: The 1.5 W adjustable Köhler NeoLED diascopic illumination is powered by an internal 100-240 V power supply making it suitable for world wide use.The innovative NeoLED design offers larger apertures, allowing the optical system of the bScope microscope to produce images at higher resolutions, very close to the theoretical diffraction limit of the optics. Other benefits of the NeoLED is the low energy consumption, no heating and a long operating lifetime
CORDLESS USE: The optional rechargeable batteries turn the bScope into a cordless system
CSS – CABLE STORAGE SYSTEM: bScope allows users to easily insert the power cable into the backside of the instrument, prevents excess cable length for a safer working environment. Roll up the cable completely for easy storage
CARRYING GRIP: The integrated carrying grip at the back of the microscope ensures safe transportation of the microscope
ANTI-THEFT SLOT: At the back of the microscope; an anti-theft slot prevent the unauthorized appropriation of the microscope
PACKAGING: Smart Styrofoam packaging ensures a low environmental footprint while maintaining maximum safety during transport. Supplied with power cord, dust cover, tools, a spare fuse, white filter, user manual and 5 ml immersion oil.
BS.1153-EPLi
- Trinocular
- HWF 10x/20 mm eyepieces
- Rackless integrated X-Y mechanical stage
- Quintuple nosepiece
- E-plan IOS 4/10/S40/S100x
- Köhler NeoLED™
- 2-position swivelling ergo head
bScope trinocular microscope with 5mp camera 10x/20 mm eyepieces and quintuple
nosepiece with E-plan EPLi 4/10/S40/S100x oil infinity corrected IOS objectives,
131 x 152/197 mm stage with integrated mechanical 75 x 36 mm rackless X-Y
stage. 3 W NeoLED™ Köhler illumination and integrated power supply
